FG-OF
FLYGOO
The Flygoo ozone machine is an ideal solution for waste water treatment in municipal and industrial facilities that require high-quality water purification. This system purifies water without using harmful chemicals and is environmentally friendly. It is also highly effective in eliminating bacteria, viruses, and other microorganisms that cause water-borne diseases.
Item | Unit | FG-OF | ||
Ozone Output | g/hr | 20 | 30 | 40 |
Power | w | 750 | 850 | 950 |
Electric | VAC/Hz | 220~240/50~60 | ||
Ozone Concentration | mg/l | Oxygen supply:80~120 | ||
Oxygen Concentration | % | 90-94.4 | ||
Oxygen Flow Rate | L/Min | 5 | 8 | 8 |
Size(L*W*H) | mm | 560*420*880 | ||
Weight | kg | 56 | 57 | 58 |
Water Cooling (22ºC) | m3/h | 0.2~0.3 | ||
Inner Air Compressor | Yes/No | Yes | ||
Ambient Humidity | % | <70 | ||
Ambient Temperature | ºC | <40 | ||
Warranty | Year | 1 | ||
Ozone Generator Features:
1. The equipment utilize a molecular sieve as an adsorbent from the top quality joint venture,and .PSA oxygen generating equipment provide you with the purity of 90%~95% oxygen to meet all requirements; Installation and operation costs far less than cylinder or liquefied oxygen.
2. Multi-point malfunction monitoring, main board temperature detection, high voltage transformer temperature detection,over current protection detection,etc. The equipment stop operation and the corresponding fault indicator on the control panel lights up when a fault is detected.
3. The equipment utilized large power IGBT modules,extremely stable,high efficiency,long lifespan dehydroxylation quartz structure,air cooling parts ,world-class essential components and world-leading intelligent design.
4.Adjustable oxygen flow rate, which will change ozone output & concentration for meeting with different lines requirements.
5. With ultra-filter and condenser for removing water in the air which can protect the oxygen &ozone unit for long service life in good working condition
6. Ozone output adjustable, with low noise level
7. Stainless steel / Painted steel case and SUS304 ozone outlet
❓1.What are the limitations of ozone water treatment?
✔ Higher upfront cost than chlorine
✔ Requires electricity and proper system design
✔ Short-lived, so no residual disinfection
✔ Can corrode certain materials (e.g., rubber, some plastics)
❓2.Can ozone be used with other water treatment methods?
✔ Yes, ozone is often combined with:
- UV disinfection
- Activated carbon filtration
- **Reverse osmosis (RO)
- Chlorination (for residual disinfection)
❓3.How do I choose the right ozone generator for my needs?
✔ Consider:
- Water flow rate (gallons/liters per minute)
- Contaminant level
- Ozone output (grams/hour)
- Installation requirements
For more details, consult QLOZONE- expert or ozone system manufacturer.
