FG-OF
FLYGOO
Turnkey oxygen feed ozone generator with built-in oxygen concentrator. 3-10g/h output, 90-95% oxygen purity, adjustable 20-100%. CE certified. Ideal for pools, drinking water, aquaculture.
The Flygoo OzonAqua Series is a turnkey ozone generator with an integrated oxygen concentrator. Simply plug into electrical power and produce both oxygen and ozone from one device. This system delivers 3-10g/hr ozone from the integrated oxygen generator (free of nitrogen oxide). Available in air-cooled, wall-mount, or floor-standing configurations, it is extremely versatile and easy to use.
Powered by advanced corona discharge technology, our industrial ozone generators deliver versatile, chemical-free disinfection across a wide spectrum of demanding environments. From pure water bottling and intensive RAS aquaculture to heavy commercial laundry and industrial effluent oxidation, the system provides powerful, eco-friendly sterilization with zero toxic residues.
High efficiency and longevity with imported HQG quartz tube and stainless steel 316L electrode.
Integrated oil-free air compressor for easy installation and reliable performance.
Precise control from 20% to 100% for every application.
Continuous and reliable operation with high-CFM internal cooling fans and slotted louvers.
Plug-and-play setup with clear control panel and status indicators.
Low maintenance and proven durability, with a robust stainless steel casing.
Item | Unit | FG-OF | |||
Ozone Output | g/hr | 3 | 5 | 7 | 10 |
Ref. Pool Volume* | g/hr | 60,000 | 80,000 | 90,000 | 100,000 |
Power | W | 370 | 380 | 390 | 415 |
Electric | VAC/Hz | 220~240/50~60 ; 110/60 | |||
Ozone Control | % | 20-100 | |||
Oxygen Flow Rate | L/Min | 3 | 3 | 3 | 3 |
Ozone Concentration | mg/l | Oxygen supply:30-50 | |||
External Case | / | Stainless steel / Stainless steel + painted | |||
Size(L*W*H) | Mm | 450*260*610mm | |||
Weight | kg | 21 | 21.5 | 22 | 23 |
Cooling System | - | Air Cooling | |||
Inner Air Compressor | Yes/No | Yes | |||
Ambient Humidity | % | <70 | |||
Ambient Temperature | °C | <40 | |||
| / | check valve 1 ; teflon tube 1 ; air stone *1 | |||
Replace chlorine, enjoy crystal clear water. Up to 80%-90% reduction in chlorine and chemical consumption, while extending the lifespan of pool liners, plumbing, and filtration equipment. Instant destruction of chlorine-resistant pathogens such as Cryptosporidium parvum, Giardia, and biofilm. Total elimination of chloramines and chemical odors—stops red eyes, itchy skin, and respiratory irritation.
Safe, odor-free water for human consumption. The integrated oxygen concentrator provides high-purity oxygen for efficient ozone generation, ensuring reliable disinfection without chemical residues.
Remove odors and pathogens in every wash. The OzonAqua system delivers powerful oxidation for commercial laundry applications, reducing detergent use and extending linen life.
Effective dechlorination and oxidation for industrial effluent. The system handles high-demand commercial and industrial water treatment with zero toxic residues.
Improve fish health and yield. Ozone treatment controls pathogens, improves water quality, and supports intensive RAS aquaculture operations.
Control bioculture and corrosion. Ozone effectively manages microbial growth and scale in cooling tower water systems.
An oxygen feed ozone generator uses concentrated oxygen (90-95% purity) from a built-in oxygen concentrator as feed gas, producing higher ozone concentration (30-50 mg/L) and more stable output than air source models. This makes it ideal for applications requiring high-efficiency oxidation, such as swimming pools and drinking water treatment.
We recommend:
FG-OF 3G: Up to 60,000 liters
FG-OF 5G: Up to 80,000 liters
FG-OF 7G: Up to 90,000 liters
FG-OF 10G: Up to 100,000 liters
Note: Actual sizing depends on humidity, water quality, and temperature. Please consult our team for a tailored recommendation.
No. The OzonAqua series integrates a PSA oxygen concentrator that separates oxygen from ambient air. Simply plug into electrical power and the system produces both oxygen and ozone from one device.
The built-in oxygen concentrator delivers 90-95% oxygen purity. The ozone concentration output is 30-50 mg/L under oxygen supply, significantly higher than air source models.
Yes. All models feature an ozone regulation knob allowing adjustable output from 20-100%. This enables precise control for different water volumes, contamination levels, and treatment requirements.
Maintenance is minimal. Key tasks include: periodic cleaning of the air intake filter, checking the cooling fan, and inspecting the ozone tube every 6-12 months. The molecular sieve and ozone tube are designed for long service life. Detailed maintenance guides are provided.
To learn more about ozone generators, please contact Flygoo Ozone Sales:
